206-100BPAV0引线玻璃保险丝盒6*30
- 2023-08-11 17:57:43
- 0
引线玻璃保险丝盒 | Glass FUSE BOX
组装带引线14AWG-20AWG |Assembly with lead 14AWG - 20AWG
型号 | model: 206-100BPAV0
| Contact | Bronze, Tin/Nickel Plated |
| With Other Wire Size Or Legths Available On Special Order. | |
| To Install Fuses With "Loop" Type Wires, Simply Cut Loop Into Two Separate Wires Of Desired Length. | |
| Body Material | Nylon PA66 |
| Applicable Fuse | 6.35*32MM/6.35*30MM |
| Wires | 14#,16#,18#.20#. |
| Length | 8" Loop. |
| Rated Current | 20AMP MAX. |
| Interlock Type. | |
| Part Number | Description |
| 206-100BPAV0 | 14GA Pated to 20 AMP |
| 206-100BPAV0 | 14 GA Pated to 20 AMP |
| 206-100BPAV0 | 16 GA Pated to 15 AMP |
| 206-100BPAV0 | 18 GA Pated to 10 AMP |
厂家长期供应引线汽车保险丝座、保险丝、汽车保险丝座、保险丝座、汽车保险丝座、玻璃保险丝等
