引线玻璃保险丝盒 | Glass FUSE BOX
组装带引线16AWG-20AWG |Assembly with lead 16AWG - 20AWG
型号 | model: 204-B601
| Contact | Bronze, Tin/Nickel Plated |
| With Other Wire Size Or Legths Available On Special Order. | |
| To Install Fuses With "Loop" Type Wires, Simply Cut Loop Into Two Separate Wires Of Desired Length. | |
| Body Material | Nylon PA-66. |
| Applicable Fuse | 5.2*20mm |
| Wires | 18#,20#. |
| Length | 8" Loop. |
| Rated Current | 20AMP MAX. |
| Interlock Type. | |
| Part Number | Description |
| 204-B601 | 18 GA Pated to 10 AMP |
| 204-B602 | 20 GA Pated to 5 AMP |
