452/454 系列贴片保险丝
分类 | 贴片保险丝 |
SKU | |
单位 |
产品详情
厂家长期供应引线汽车保险丝座、保险丝、汽车保险丝座、保险丝座、汽车保险丝座、玻璃保险丝等
Description
The NANO Slo-Blo fuse has enhanced inrush withstand characteristics over the NANo Fast-Acting fuse. The unique time delay feature of this fuse design helps solve the problem of nuisance "opening" by accommodating inrush currents that normally cause a fast-acting fuse to open.
Agency Approvals
AGENDY | AGENDY FILE NUMBER | AMPERE RANGE |
E10480 | 375mA~12A | |
LR29862 | 375mA~12A | |
NBK030205-E1048OB | 1A!5A |
Electrical Characteristics for Series
% Of Ampere Rating | Opening Time At 25℃ |
100% | 4hours,Minimum |
200% | 1 sec,Min.;60 sec.,Max. |
300% | 0.2 sec.,Min.;3 sec.,Max. |
800% | 0.2 sec.,Min.;0.1 sec.,Max. |
Features
Time-Lag(Slo-Blo) |
Small size |
Wide range of current rating available(375mA to 12A) |
Wide operating temperature range |
Low temperature de-rating |
RoHS compliant |
Halogen Fress |
Electrical Specifications by item
Ampere Rating (A) |
Amp Code |
Max Voltage Rating (V) |
Interrupting Rating |
Nominal Cold Melting (Ohms) |
Mominal Melting I2t (A2sec) |
Angency Approvals |
||
0.375 | .375 | 125 |
50 amperes @ 125 VAC/VDC 300 amperes @ 32 VDC PSE:100 amperes @ 100VAC |
1.2000 | 0.101 | X | X | |
0.500 | .500 | 125 | 0.7000 | 0.240 | X | X | ||
0.750 | .750 | 125 | 0.360 | 0.904 | X | X | ||
001. | 001. | 125 | 0.2250 | 1.98 | X | X | ||
1.50 | 01.5 | 125 | 0.0930 | 3.65 | X | X | X | |
2.00 | 002. | 125 | 0.0625 | 8.20 | X | X | X | |
2.50 | 02.5 | 125 | 0.0450 | 15.0 | X | X | X | |
3.00 | 003. | 125 | 0.0340 | 20.16 | X | X | X | |
3.50 | 03.5 | 125 | 0.0224 | 26.53 | X | X | X | |
4.00 | 004. | 125 | 0.0186 | 34.40 | X | X | X | |
5.00 | 005. | 125 | 0.0136 | 53.72 | X | X | X | |
7.00 | 007. | 72 |
50 amperes @ 72 VAC 50amperes @ 60 VDC |
0.0105 | 123.83 | X | X | |
8 | 008. | 72 |
50 amperes @ 72 VAC 50amperes @ 60 VDC |
0.0088 | 137.34 | X | X | |
12 | 012. | 72 | 0.0061 | 260.46 | X | X |
